Vacuum Globe Valve

Product Features

Characteristics:

1. The fluid resistance is small, and its resistance coefficient is equal to that of a pipe section of the same length.

2. It has simple structure, small size and light weight.

3. Tight and reliable, the sealing surface material of the gate valve is widely made of plastic, which has good sealing performance and has also been widely used in vacuum systems.

4. It is easy to operate and opens and closes quickly. It only needs to be rotated 90° from fully open to fully closed, which is convenient for long-distance control.

5. It is easy to maintain. The gate valve has a simple structure and the sealing ring is generally movable, making it easy to disassemble and replace.

6. When fully open or fully closed, the sealing surfaces of the ball and valve seat are isolated from the medium. When the medium passes, it will not cause erosion of the valve sealing surface.

7. It has a wide range of applications, with diameters ranging from a few millimeters to several meters, and can be applied from high vacuum to high pressure.


Nominal pressure
CLASS
Nominal diameter
IN(mm)
LDD1D2D0HH1Weight(kg)
Manual operationpower-driven
300LB22301651279220032056019 73
21/2290190149.210525033557522 77
3310210168.312725039568531 85
435025520015732041570545105
540028023518632046076075175
6480320269.921635051081095195
8600380330.22705506251010165295
10650445387.43246007801294230475
12750520450.83816508551465325775
600LB23001651279224042071040 94
21/2340190149.210526047076048106
3380210168.312730056086056156
4430275215.915740063093080180
5500330266.71865007501168125257
6550355292.12165008501364200445

Nominal pressure
CLASS

Nominal dimeter
IN(mm)
Standard valueReference value
 L DD1 D2D6bf f1Z- φdD0HWeight(kg)
150LB2230152120.592
192
4-1920032519
21/2290178139.5105
22.52
4-1925034522
3310190152.5127
23.92
4-1925036033
4350229190.5157
23.92
8-1932037018
5400254216186
23.92
8-2232048085
9480279241.5216
25.42
8-22320598105
8600343298.5270
28.52
8-22400702178
10650406362324
312
12-25400782446
12750483432381
322
12-25500880456
300LB2230165127928822.7248--1820035023
21/2290190149.210511025.9248--2225040028
3310210168.312712129248--2225043033
435025520015715032.22 4.58--2232046553
540028023518617635.42 4.58-2232050593
6480320269.9216204372 4.512--22320611115
8600380330.227026041.72 4.512--26400722210
600LB2300165127928825.4748--1828041449
21/2340190149.210511028.6748--2232046465
3380210168.312712131.8748--2240054795
4430275215.915715038.17 4.58--26450621115
5500330266.718617644.57 4.58--30450732149
6550355292.121620447.77 4.512--30500840310
8 650420249.227026055.67 4.512--33 550 925590
Product
  type
Shell
strength test/MPa
Back
seal test/MPa
seal test/MPaApplicable
medium
Applicable
temperature/℃
NKJ61H-406.04.44.4Water,
  Steam
   Air
≤425
NKJ61H-609.67.07.0
NKJ61H-10015.011.011.0
NKJ61Y-4016.04.44.4Water,
Steam,
   Air
≤550
NKJ61Y-64I9.67.07.0
NKJ61Y-10015.011.011.0
Part
name
Body
Bonnet
Valve
stem
DiscSealing
face
Yoke nutPackingFastener
NKJ61H
-C
25 or WCBCr.stain
mless
steel
Cr.stain
mless
steel
H: alloy
steel
Al
bronze
Expandng
compound
graphite
High
grade
carbon
  steel
NKJ61H
-1
Cr.Mo
steel
20Cr1
Mo1VA or 38Cr
MoAIA
12Cr1Mo
1VA
Y:carbide
alloy
Cr.MO
steel
